SAE 100 R1 A

HIGH PRESSURE WIRE BRAIDED HOSE

TUBE: Black oil resistant synthetic rubber
REINFORCEMENT: 1 Wire braid
COVER: Black oil resistant synthetic rubber
OPERATING TEMPERATURE RANGE: -40°C to +100°C

Nom size.

 I.D. O.D. Working press. Min. Burst. press. Min. Bend   Radius.

mm.

 in. mm. in. PSI. Bar. PSI. Bar. mm. in.
3/16 4.8 .188 12.7 .500 3000 207 12000 827 89 3.50
1/4 6.3 .250 16.0 .630 2750 190 11000 758 102 4.00
5/16 8.0 .312 17.5 .689 2500 172 10000 689 114 4.50
3/8 9.5 .375 20.0 .787 2250 155 9000 620 127 5.00
1/2 12.7 .500 23.0 .905 2000 138 8000 552 178 7.00
5/8 16.0 .625 26.0 1.023 1500 103 6000 414 203 8.00
3/4 19.0 .750 30.0 1.181 1250 86 5000 345 241 9.50
1 25.4 1.000 38.0 1.496 1000 69 4000 276 305 12.00
1.1/4 32.0 1.250 46.0 1.811 625 43 2500 172 419 16.50
1.1/2 38.0 1.500 52.0 2.047 500 34 2000 138 508 20.00
2 50.8 2.000 67.0 2.638 375 26 1500 103 635 25.00

SAE 100 R2 A

HIGH PRESSURE WIRE BRAIDED HOSE

TUBE: Black oil resistant synthetic rubber
REINFORCEMENT: 2 Wire braid
COVER: Black oil resistant synthetic rubber
OPERATING TEMPERATURE RANGE: -40°C to +100°C

Nom size.

 I.D. O.D. Working press. Min. Burst. press. Min. Bend  Radius.

mm.

 in. mm. in. PSI. Bar. PSI. Bar. mm. in.
3/16 4.8 .188 16.0 .630 5000 345 20000 1379 89 3.50
1/4 6.3 .250 17.5 .689 5000 345 20000 1379 102 4.00
5/16 8.0 . 312 19.0 .748 4250 293 17000 1172 114 4.50
3/8 9. 5 .375 21.5 .846 4000 276 16000 1103 127 5.00
1/2 12.7 .500 24. 5 .964 3500 241 14000 965 178 7.00
5/8 16.0 .625 28.0 1.102 2750 190 11000 758 203 8.00
3/4 19.0 .750 32.0 1.260 2250 155 9000 620 241 9.50
1 25.4 1.000 39.5 1.555 2000 138 8000 552 305 12.00
1.1/4 32.0 1.250 51.0 2.000 1625 112 6500 488 419 16.50
1.1/2 38.0 1.500 57.0 2.244 1250 86 5000 345 508 20.00
2 50.8 2.000 70.0 2.756 1125 78 4500 310 635 25.00



SAE 100 R3

MEDIUM PRESSURE TEXTILE BRAIDED HOSE

TUBE: Black oil resistant synthetic rubber
REINFORCEMENT: 2 Textile braids
COVER: Black oil resistant synthetic rubber
OPERATING TEMPERATURE RANGE: -40°C to +93°C

Nom size.

 I.D. O.D. Working press. Min. Burst. press. Min. Bend  Radius.

mm.

 in. mm. in. PSI. Bar. PSI. Bar. mm. in.
3/16 4.8 .188 12.7 .500 1500 105 6000 422 76 3.00
1/4 6.3 .250 14.3 .563 1250 88 5000 352 76 3.00
5/16 8.0 . 312 17.5 .687 1200 84 4800 338 102 4.00
3/8 9. 5 .375 19.1 .750 1125 79 4500 316 102 4.00
1/2 12.7 .500 23.8 .937 1000 70 4000 281 127 5.00
5/8 16.0 .625 27.0 1.063 875 62 3500 246 140 5.50
3/4 19.0 .750 31.8 1.250 750 53 2000 211 152 6.00
1 25.4 1.000 38.1 1.500 565 40 2250 158 203 8.00
1.1/4 31.8 1.250 44.4 1.750 375 26 1500 105 254 10.00
1.1/2 38.0 1.500 50.8 2.000 250 17 1000 69 305 12.00
2 50.8 2.000 64.0 2.520 217 15 868 60 410 16.00



SAE 100 R4

Delivery /Suction Hose

TUBE: Synthetic oil resistant rubber with supporting wire helix
REINFORCEMENT: 2 Rayon braids
COVER: Synthetic rubber -abrasion ,ozone, and weather resistant
OPERATING TEMPERATURE RANGE: -40°C to +120°C

Hose Refrence

 I.D. O.D. Working press. Min. Burst. press. Min. Bend  Radius.

mm.

 in. mm. in. PSI.Bar. PSI. Bar. mm. in.
406 19.0 3/4 34.9 1.354 30020.7 1200 82.8 127 5.00
407 25.4 1 41.3 1.626 25017.2 1000 68.8 152 6.00
408 31.8 1  1/4 50.8 2.000 20013.8 800 55.2 203 8.00
409 38.1 1  1/2 57.2 2.252 15010.3 600 41.2 254 10.00
410 50.8 2 69.9 2.752 1006.9 400 27.6 305 12.00
412 63.5 2  1/2 82.0 3.228 624.3 250 17.2 356 14.00
413 76.2 3 95.0 3.740 563.8 255 15.5 457 18.00

SAE 100 R5MEDIUM PRESSURE WIRE AND TEXTILE BRAIDED HOSE (RUBBER/TEXTILE COVER)

TUBE: Black oil resistant synthetic rubber
REINFORCEMENT: 1 wire braid between 2 textile braids
COVER: Rubber cover/textile outer braid impregnated with oil resistant rubber
OPERATING TEMPERATURE RANGE: -40°C to +93°C

Nom size.

 I.D. O.D. Working press. Min. Burst. press. Min. Bend  Radius.

mm.

 in. mm. in. PSI.Bar. PSI. Bar. mm. in.
3/16 4.8 .188 13.2 .519 3000211 12000 844 76 3.00
1/4 6.3 .250 14.8 .581 3000211 12000 844 86 3.38
5/16 8.0 . 312 17.2 .676 2250158 9000 633 102 4.00
13/32 10.3 .406 19.4 .766 2000141 8000 562 117 4.62
1/2 12.7 .500 23.4 .922 1750123 7000 492 140 5.50
5/8 16.0 .625 27.4 1.078 1500105 6000 422 165 6.50
7/8 22.2 .875 31.5 1.234 80056 3200 225 187 7.38
1.1/8 28.0 1.125 38.1 1.500 62544 2500 176 229 9.00
1.3/8 35.0 1.375 44.4 1.750 50035 2000 141 267 10.50
1.13/16 46.0 1.812 56.4 2.319 35024 1400 99 337 13.25
2.3/8 60.3 2.375 73.0 2.874 30021 1200 84 530 20.87

SAE 100 R6LOW PRESSURE TEXTILE BRAIDED HOSE

TUBE: Black oil resistant synthetic rubber
REINFORCEMENT: 1 Textile braid
COVER: Black oil resistant synthetic rubber
OPERATING TEMPERATURE RANGE: -40°C to +93°C

Nom size.

 I.D. O.D. Working press. Min. Burst. press. Min. Bend  Radius.

mm.

 in. mm. in. PSI.Bar. PSI. Bar. mm. in.
3/16 4.8 .188 11.1 .437 50035 2000 141 51 2.00
1/4 6.3 .250 12.7 .500 40028 1600 113 64 2.50
5/16 8.0 . 312 14.3 .563 40028 1600 113 76 3.00
3/8 9. 5 .375 15.9 .625 40028 1600 113 76 3.00
1/2 12.7 .500 19.8 .781 40028 1600 113 102 4.00
5/8 16.0 .625 23.0 .906 35025 1400 98 127 5.00
3/4 19.0 .750 26.0 1.023 25017 1000 70 177 7.00

 SAE 100 R7 TYPE 1 SERIES 701 HI-TEMPERATURE STEAM HOSE

BS5342-1977 TYPE1   ISO 6134-1981 TYPE2    IS 10655-1983 TYPE 3

Application Construction: Steam at high temperature
Tube: Steam and heat resistant EPDM rubber
Reinforcement: 1 high tensile steel wire braid
Cover: Synthetic rubber-heat, abrasion, ozone and weather resistant
Temp. range: Upto 150°C
Hose Ref. Dash no DN Inside Diameter Mean Outer Cover Diam Max Steam Working Press Min Hydrostatic Burst Press Min Bend Radius
inch mm inch mm psi bar psi bar inch mm
SH101 -4 6 1/4 6.4 0.590 15.0 150 10 2320 160 4.0 102
SH102 -5 8 5/16 7.9 0.673 17.1 150 10 2320 160 4.5 114
SH103 -6 10 3/8 9.5 0.787 20.0 150 10 2320 160 5.0 127
SH104 -8 12 1/2 12.7 0.972 24.7 150 10 2320 160 7.0 178
SH105 -10 16 5/8 15.9 1.098 27.9 150 10 2320 160 8.0 203
SH106 -12 20 3/4 19.0 1.236 31.4 150 10 2320 160 9.5 241
SH107 -16 25 1 25.4 1.496 38.0 150 10 2320 160 12.0 305
SH108 -20 32 11/4 31.8 1.858 47.2 150 10 2320 160 16.5 419
SH109 -24 40 11/2 38.1 2.106 53.5 150 10 1450 100 20.0 508
SH110 -32 50 2 50.8 2.630 66.8 150 10 1450 100 25.0 635





SAE 100 R7 TYPE 2

SERIES 702 EXTRA HI-TEMPERATURE STEAM HOSE

BS 5342-1977 TYPE 2   ISO 6134-1981 TYPE 3   IS 10655-1983 TYPE 4

[FrontPage Save Results Component]
Application Construction: Steam at high temperature
Tube: Steam and heat resistant EPDM rubber
Reinforcement: 2 high tensile steel wire braids
Cover: Synthetic rubber-heat, abrasion, ozone and weather resistant
Temp. range: Upto 205°C
Hose Reference Dash no DN Inside Diameter Mean Outer Cover Diam Max Steam Working Press Min Hydrostatic Burst Press Min Bend Radius
inch mm inch mm psi bar psi bar inch mm
SH201 -4 6 1/4 6.4 0.669 17.0 232 16 2320 160 4.0 102
SH202 -5 8 5/16 7.9 0.752 19.1 232 16 2320 160 4.5 114
SH203 -6 10 3/8 9.5 0.866 22.0 232 16 2320 160 5.0 127
SH204 -8 12 1/2 12.7 1.051 26.7 232 16 2320 160 7.0 178
SH205 -10 16 5/8 15.9 1.177 29.9 232 16 2320 160 8.0 203
SH206 -12 20 3/4 19.0 1.315 33.4 232 16 2320 160 9.5 241
SH207 -16 25 1 25.4 1.575 40.0 232 16 2320 160 12.0 305
SH208 -20 32 11/4 31.8 1.968 50.0 232 16 2320 160 16.5 419
SH209 -24 40 11/2 38.1 2.232 56.7 232 16 2320 160 20.0 508
SH210 -32 50 2 50.8 2.756 70.0 232 16 2320 160 25.0 635







SAE 100 R9

HIGH PRESSURE WIRE SPIRAL HOSE

TUBE: Black oil resistant synthetic rubber
REINFORCEMENT:4 High tensile wire spiral
COVER: Black oil resistant synthetic rubber
OPERATING TEMPERATURE RANGE: -40°C to +121°C

Nom size.

 I.D. O.D. Working press. Min. Burst. press. Min. Bend  Radius.

mm.

 in. mm. in. PSI. Bar. PSI. Bar. mm. in.
3/8 9.5 .375 21.4 .842 4500 310 18000 1241 127 5.00
1/2 12.7 .500 24.6 .968 4000 276 16000 1103 178 7.00
3/4 19.0 .750 31.3 1.232 3000 207 12000 827 240 9.50
1 25.4 1.000 39.7 1.562 3000 207 12000 827 300 12.00



SAE 100 R12

HIGH PRESSURE WIRE SPIRAL HOSE

TUBE: Black oil resistant synthetic rubber
REINFORCEMENT: 4 High tensile wire spirals
COVER: Black oil resistant synthetic rubber
OPERATING TEMPERATURE RANGE: -40°C to +121°C

Nom size.

 I.D. O.D. Working press. Min. Burst. press. Min. Bend  Radius.

mm.

 in. mm. in. PSI. Bar. PSI. Bar. mm. in.
3/8 9.5 0.375 20.0 0.787 4000 276 16000 1103 127 5.00
1/2 12.7 0.500 23.8 0.937 4000 276 16000 1103 178 7.00
3/4 19.0 0.750 30.7 1.208 4000 276 16000 1103 241 9.50
1 25.4 1.000 38.0 1.5 4000 276 16000 1103 305 12.00
1.1/4 31.8 1.250 47.0 1.850 3000 207 12000 827 419 16.50
1.1/2 38.1 1.500 53.5 2.106 2500 172 10000 690 508 20.00
2 50.8 2.000 66.7 2.625 2500 172 10000 690 635 25.00



SAE 100 R13

SUPER HIGH PRESSURE WIRE SPIRAL HOSE

TUBE: Black oil resistant synthetic rubber
REINFORCEMENT:4/6  High tensile wire spirals
COVER: Black oil resistant synthetic rubber
OPERATING TEMPERATURE RANGE: -40°C to +121°C

Nom size.

 I.D. O.D. Working press. Min. Burst. press. Min. Bend  Radius.

mm.

 in. mm. in. PSI. Bar. PSI. Bar. mm. in.
1/4 6.3 .250 20.4 .803 11250 776 45000 3103 127 5.00
3/8 9.5 .375 23.8 .937 10000 690 40000 2758 152 6.00
1/2 12.7 .500 27.0 1.063 7500 517 30000 2068 200 8.00
3/4 19.0 .750 32.0 1.260 5000 345 20000 1379 240 9.50
1 25.4 1.000 39.2 1.543 5000 345 20000 1379 300 12.00
1.1/4* 32.0 1.250 49.8 1.960 5000 345 20000 1379 419 16.50
1.1/2* 38.0 1.500 57.3 2.255 5000 345 20000 1379 500 20.00
2* 50.8 2.000 71.0 2.795 5000 345 20000 1379 630 25.00





DIN 20023-4 SP

 HIGH PRESSURE WIRE SPIRAL HOSE

TUBE: Black oil resistant synthetic rubber
REINFORCEMENT:4 High tensile wire spirals
COVER: Black oil resistant synthetic rubber
OPERATING TEMPERATURE RANGE: -40°C to +121°C

Nom size.

 I.D. O.D. Working press. Min. Burst. press. Min. Bend  Radius.

mm.

 in. mm. in. PSI. Bar. PSI. Bar. mm. in.
1/4 6.3 .250 17.8 .700 6525 450 26100 1800 150 6.00
3/8 9.5 .375 21.4 .842 6450 445 25800 1780 178 7.00
1/2 12.7 .500 24.6 .968 6020 415 24070 1660 230 9.00
5/8 16.0 .625 28.5 1.122 5075 350 20300 1400 250 10.00
3/4 19.0 .750 32.0 1.260 5075 350 20300 1400 300 12.00
1 25.4 1.000 39.7 1.563 4060 280 16240 1120 340 13.00
1.1/4 32.0 1.250 50.8 2.000 3045 210 12180 840 457 18.00
1.1/2 38.0 1.500 57.0 2.244 2680 185 10730 740 559 22.00
2 50.8 2.000 70.6 2.780 2500 172 10000 689 660 26.00



DIN 20023 TYPE 4 SH

 HIGH PRESSURE WIRE SPIRAL HOSE

TUBE: Black oil resistant synthetic rubber
REINFORCEMENT:4 High tensile wire spirals
COVER: Black oil resistant synthetic rubber
OPERATING TEMPERATURE RANGE: -40°C to +121°C

Nom size.

 I.D. O.D. Working press. Min. Burst. press. Min. Bend  Radius.

mm.

 in. mm. in. PSI. Bar. PSI. Bar. mm. in.
3/4 19.0 .750 32.0 1.250 6090 420 24360 1680 280 11.00
1 25.4 1.000 38.0 1.500 5510 380 22040 1520 340 13.40
1.1/4 32.0 1.250 45.2 1.780 4715 325 18850 1300 460 18.11
1.1/2 38.0 1.500 53.5 2.105 4205 290 16820 1160 560 22.05
2 50.8 2.000 68.0 2.675 3625 250 14500 1000 700 27.55
